- Acoustic power emissions (active, printing)
- 5.5 B(A)
- Automatic document feeder capacity
- Standard, 100 sheets
- Automatic document feeder scan speed
- Up to 80 ppm/160 ipm (b&w, color, 300 dpi)
- Bit depth
- 24-bit (external), 48-bit (internal)
- Cable included
- Yes, 1 USB and 3 power cables
- Cartons per layer
- 6
- Certifications and compliances
- Compatible with optional SmartCard Solution for US Gov't- CCID compliant CAC reader
- Color scanning
- Yes
- Compatible Operating Systems
- Windows 11; Windows 10; Windows 8.1; Windows Server; macOS 10.15 Catalina; macOS 11 Big Sur; macOS 12 Monterey; macOS 13 Ventura; macOS 14 Sonoma; macOS 15 Sequoia; Linux
- Component type
- Printer
- Configurable items
- 80ppm/160ipm; Duplex; 100/100 sheets ADF; Zonal OCR; Scan to USB 3.0; Daily Duty cycle up to 30,000 pages per day; Modern Design; 30% RCP; Secure boot; Firmware code signing; No assembly setup.
- Connectivity, standard
- 1 SuperSpeed USB 3.0
- Consumables CO2e (kg)
- 12
- Control panel
- 2-line 16 character per line LCD display, Simplex button, Duplex button, Cancel button, Power button with a LED and Tool button
- Count of layers in pallet
- 6 (High Cube container); 5 (Standard container)
- Country of origin
- Made in China; Made in Taiwan
- Digital sending standard features
- Scan to PC; Scan to USB Drive; Scan to Email; Scan to Network Folder; Scan to SharePoint; Scan to Shortcut; Scan to Cloud
- Dimensions (W x D x H)
- 15.3 x 11 x 10 in
- Display
- 2-line 16 character per line LCD display
- Document weight ADF (maximum)
- 112.5 lb
- Document weight ADF (minimum)
- 7.5 lb
- Duplex ADF scanning
- Yes
- Duty cycle (daily)
- Recommended daily duty cycle: 30,000 pages
- Ecolabels
- IT ECO Declaration; EPEAT® registered; ENERGY STAR® certified
- Ecolabels footnote
- [2] This product is EPEAT Silver certified. Status varies by country. Visit https://www.epeat.net for more information.
- End of Life CO2e (kg)
- 0.2
- Energy star certified
- Yes
- Energy Usage CO2e (kg)
- 367
- Enhanced scanning resolution
- Up to 1200 dpi
- Image scaling or enlargement range
- Will not perform any arbitrary scaling
- Levels of grayscale
- 256
- Light source (scanning)
- Light Emitting Diode (LED)
- Mac compatible
- Yes
- Manufacturer Warranty
- One-year limited hardware warranty, phone and Web support included. Warranty may vary by country as required by law.
- Material Type for item
- FERT
- Maximum dimensions (W x D x H)
- 15.3 x 26 x 15.2 in
- Media size (ADF)
- US letter, US legal, US Executive, A3, A4, B5, A5, A6, A7, A8; 69 x 50.8 mm to 297 x 5842 mm
- Media types
- Cut Sheet Paper, Printed Paper (Laser and ink), Pre-Punched Paper, Bank Checks, Business Cards, Carbonless forms, Previously stapled media with staple removed, Carrier sheet purchased
- Media weights, supported ADF
- 7.5 to 112.5 lb
- Memory
- 1 GB
- Minimum System Requirements
- Microsoft Windows 11, 10, 8.1, 2008 R2, 2012 R2, 2016, 2019; 2 GB available hard disk space, Internet Required, Web Browser, USB
- Minimum System Requirements for Macintosh
- macOS Catalina v 10.15, macOS Big Sur v 11, macOS Monterrey v 12, macOS Ventura v 13, macOS Sonoma v 14; Internet Required; USB
- Multifeed detection
- Yes
- Non-Operating Humidity Range
- 0 to 90% RH (non-condensing)
- Operating humidity range
- 15 to 80% RH (non-condensing)
- Operating temperature range
- 50 to 95°F
- Output resolution dpi settings
- 75; 150; 200; 240; 300; 400; 500; 600; 1200 ppi
- Package dimensions (W x D x H)
- 19.49 x 13.74 x 15.12 in
- Package weight
- ~19.51 lb
- Pallet dimensions
- Wood palet: 47.24 x 39.37 x 80.55 in; Slip sheet: 41.22 x 38.98 x 75.63 in
- Pallet weight
- Wood pallet: 611 lb; Slip sheet: 589 lb
- Power
- Input Voltage range: 90- 264 VAC, Rated Frequency: 50- 60HZ, Worldwide use
- Power consumption
- 6.5 watts (ready), 1.2 watts (sleep), 0.08 watts (off)
- Power supply type
- External power adapter
- Processor speed
- 666 MHz
- Product long name specifications
- 80ppm/160ipm; 100 A4-/100 A3 sheet ADF; Daily Duty Cycle up to 30,000; USB 3.0;
- Production CO2e (kg)
- 366
- Quantity per pallet
- 36 (High Cube container); 30 (Standard container)
- Recommended operating humidity range
- 30 to 70% RH
- Recommended operating temperature range
- 63.5 to 77°F
- Registration required
- No
- RMN number
- SEOLB-2300-00
- Scan file format
- BMP; CSV; Excel (XLS); Excel ( XLSX); JPEG; JPG; PDF; PDF/A; webp; RTF; Searchable PDF; TIFF; TXT; Word (DOC); Word (DOCX); XML; XPS
- Scan input modes
- Two scan modes (simplex/duplex) on front-panel for scan in Win OS, Easy Scan/ICA in Mac OS and third parties applications via TWAIN, ISIS and WIA
- Scan resolution, hardware
- Up to 600 x 600 dpi
- Scan resolution, optical
- Up to 600 dpi
- Scan size (ADF), maximum
- 11.7 x 230 in
- Scan size (ADF), minimum
- 2 x 2.7 in
- Scan speed footnote
- Scan speed measured at 300 dpi using included Scan Premium. Actual processing speeds may vary depending on scan resolution, network conditions, computer performance, and application software.
- Scan technology
- ADF; CMOS CIS (Contact Image Sensor)
- Scanner advanced features
- Auto Document Classification; Manual Reduction; Multi Zonal OCR; Scan to Multi Destination; Auto Orientation; Blank Page Removal; Barcode Detection; Digitial Stamp; Batch Seperation; EveryPage Technology; Scan to USB.
- Scanner type
- Sheetfed
- Scanning options (ADF)
- Single-pass duplex
- Security management
- Encrypted scan data, No non-volatile storage of scan data
- Software included
- Scan Premium Software, Scanner Tools Utility, Scan Assistant, WIA scan driver, TWAIN scan driver, ISIS driver ICA driver, Easy Scan for Mac OS, UI Scan for Linux
- Storage temperature range
- -40 to 140°F
- Sustainability specifications
- FSC Certified Packaging; 30% post-consumer recycled plastic
- Tariff numbers
- 8471608000
- Total CO2e (kg)
- 760
- Transportation CO2e (kg)
- 11
- Twain version
- Version 2.4
- UNSPSC code
- 43211711
- UPC number
- (201) 198701400547; (BGJ) 198701400745
- Weight
- 10.8 lb
- What's in the box
- Power cord; adapter; USB cable; User Guide; regulatory flyer
